Barcode ActiveX Control
Install Barcode ActiveX Add-in in Excel
How to install Barcode ActiveX Add-in and toolbar in Excel
- After installation the following toolbar is available in Excel:
![](https://media.barcodewiz.com/images/758ad64e-6aea-461c-9406-25f48723309b-excel2019_1.png)
Option 1. Install using BarCodeWiz Add-ins Setup
- Ensure Excel is closed
- Go to Start button > All Programs > BarCodeWiz ActiveX X.XX > BarCodeWiz Add-Ins Setup
- Click on Click To Install
![](https://media.barcodewiz.com/images/95e5d7f9-6b4f-43bf-9d5e-b3be56392f97-excel2016_2.png)
Option 2. Manual Add-in Installation
- Click on File > Options > Add-Ins > Manage Excel Add-ins > Go...
![](https://media.barcodewiz.com/images/58b1ff24-956b-4245-a269-eaba0a645090-excel2016_4.png)
- Click on Browse...
![](https://media.barcodewiz.com/images/0c0e7314-d9cb-4dce-a5ea-0ec4eaf1426c-excel2016_5.png)
- Select the add-in. The default location is:
C:\Program Files\BarCodeWiz\BarCodeWiz ActiveX Control\Addins\BarCodeWizAX.xla
![](https://media.barcodewiz.com/images/6836ffc4-204e-4b77-ba1b-3f14f96f6261-excel2016_6_1.png)
The add-in is now installed
![](https://media.barcodewiz.com/images/67a7be38-31c2-4632-ab1a-c83cc75ee4d9-excel2016_7.png)
The toolbar is now ready
![](https://media.barcodewiz.com/images/758ad64e-6aea-461c-9406-25f48723309b-excel2019_1.png)
